TRK 502/ 502X
12
LOCATION OF PARTS
1 Clutch lever
2 Left handle switch
3 Meter
4 Right handle switch
6 Front brake lever
5 Throttle grip
7 Rear shock absorber
8 Rear brake pedal
9 Shift pedal
10 Side stand
11 Tank
Off-Road Version (A)
Left view
1
4
5
2
6
3
Right view
11
9
10
8
7
