Benelli TRK 502X User Manual

TRK 502/ 502X
33
SMOOTH LAUNCHING
Hold the clutch lever, paused for an instant and step on the shift pedal to the rst gear. Twist the throttle grip
towards yourself and release the clutch lever slowly and smoothly at the same time. Then the motorcycle will begin
to move forward smoothly.
Gear box usage
Gear box can ensure a smooth running of engine within normal engine rpm Driver should choose a proper gear
according to driving speed. It is dangerous to drive with clutch disengaged. Lower the gear when you slow down
the motorcycle to make engine run within normal rpm range.
Drive on slope way
When drive on uphill road, motorcycle will slow down and seem to be lack of power. Switch to low gears so that
engine can generate normal power. Shift the gear swiftly to prevent motorcycle from losing speed.
Turn to low speed gears in order to brake when driving on downhill slope.
Don't over rev the engine.
Brake usage and stopping
Warning:
Put the stands back to retracted position before driving.
INSPECTION& MAINTENANCE

Benelli TRK 502X Specifications

General

Displacement	500 cc
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Max Power	47.6 HP (35 kW) @ 8500 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Steel Trellis
Ground Clearance	220 mm
Fuel Tank Capacity	20 liters
Weight (Dry)	213 kg
Engine Type	Liquid cooled, 4-stroke, 2-cylinder
Max Torque	46 Nm @ 6000 rpm
Fuel System	Electronic fuel injection
Front Suspension	50 mm upside-down fork, adjustable
Rear Suspension	Single shock, adjustable
Front Brake	320 mm double disc, ABS
Rear Brake	260 mm single disc, ABS
Front Tire	110/80 R19
Rear Tire	150/70 R17
Seat Height	840 mm
