TRK 502/ 502X
46
(1) Over worn sprocket tooth (2) Broken or damaged sprocket tooth (3) Loosened sprocket xing nuts
BRAKE
The motorcycle uses disc brake as both the front brake and the rear brake. Adjustment is nished before delivery.
Contact dealer if any problem.
Brake Fluid
The motorcycle uses DOT4 brake uid. Please replace it every two years.
Don't forget to check the amount level in the front brake uid reservoir. Add appropriate brake uid if necessary.
Brake pads
Check the front and rear wheel brake pads whether have been worn to limits. Change the pads if over the limit.
INSPECTION BEFORE DRIVING
Warning：
In case of drinking the brake uid by mistake or contacting with eye or skin, wash with a large amount
of water, and seek medical advice immediately if in a serious condition.

Benelli TRK 502X Specifications

General

Displacement	500 cc
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Max Power	47.6 HP (35 kW) @ 8500 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Steel Trellis
Ground Clearance	220 mm
Fuel Tank Capacity	20 liters
Weight (Dry)	213 kg
Engine Type	Liquid cooled, 4-stroke, 2-cylinder
Max Torque	46 Nm @ 6000 rpm
Fuel System	Electronic fuel injection
Front Suspension	50 mm upside-down fork, adjustable
Rear Suspension	Single shock, adjustable
Front Brake	320 mm double disc, ABS
Rear Brake	260 mm single disc, ABS
Front Tire	110/80 R19
Rear Tire	150/70 R17
Seat Height	840 mm
