TRK 502/ 502X
45
Adjust the chain in following methods:
1. Support the motorcycle with side stand.
2. Loosen rear axle nut.
3. Loosen locknut.
4. Turn adjusting nut to adjust the tightness of the chain. Reference marks are adopted on left and right swing
arm and should reach the same grid after adjustment. Retighten the rear axle nut after adjust the chain
tightness to 28~35mm and conrm again.
During regular maintenance, check the following conditions of the chain:
(1) Loose pin (2) Damaged roller
(3) Rusty chain link (4) Twisted or snarled link
(5) Excessive free play (6) Loose chain
The sprocket is probably damaged, if any above-mentioned problems on the chain are found.
Check the following items for sprocket:
INSPECTION& MAINTENANCE
Notice:
When use new chain, check both front and rear sprockets if they are still in service limit and replace them,
if necessary

Benelli TRK 502X Specifications

General

Displacement	500 cc
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Max Power	47.6 HP (35 kW) @ 8500 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Steel Trellis
Ground Clearance	220 mm
Fuel Tank Capacity	20 liters
Weight (Dry)	213 kg
Engine Type	Liquid cooled, 4-stroke, 2-cylinder
Max Torque	46 Nm @ 6000 rpm
Fuel System	Electronic fuel injection
Front Suspension	50 mm upside-down fork, adjustable
Rear Suspension	Single shock, adjustable
Front Brake	320 mm double disc, ABS
Rear Brake	260 mm single disc, ABS
Front Tire	110/80 R19
Rear Tire	150/70 R17
Seat Height	840 mm
