TRK 502/ 502X
32
DRIVING TIPS
HOW TO START THE ENGINE
Insert the ignition key into the ignition lock and to " ". Step on the shift pedal to the neutral. The neutral
indicator light lightens up if the gear box is in neutral position. Start the engine by pushing the start switch.
Warning:
Do not start the engine indoor with bad ventilation or without ventilation. Do not leave a starting
motorcycle when no one else is around.
Caution:
Do not run the engine in high speed when you do not drive the motorcycle, or it will become overheating
and damage its inner parts.
INSPECTION BEFORE DRIVING

Benelli TRK 502X Specifications

General

Displacement	500 cc
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Max Power	47.6 HP (35 kW) @ 8500 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Steel Trellis
Ground Clearance	220 mm
Fuel Tank Capacity	20 liters
Weight (Dry)	213 kg
Engine Type	Liquid cooled, 4-stroke, 2-cylinder
Max Torque	46 Nm @ 6000 rpm
Fuel System	Electronic fuel injection
Front Suspension	50 mm upside-down fork, adjustable
Rear Suspension	Single shock, adjustable
Front Brake	320 mm double disc, ABS
Rear Brake	260 mm single disc, ABS
Front Tire	110/80 R19
Rear Tire	150/70 R17
Seat Height	840 mm
