TRK 502/ 502X
28
PRIMARY PARTS
REAR BRAKE PEDAL
SHIFT PEDAL
Alarm：
Rotate this adjusting knob with hand only, and never use too much force, or the rear suspension will be damaged.
This will be deemed as abnormal usage, will not be covered by warranty.
REAR BRAKE PEDAL
Step the rear brake pedal to slow down
the rear wheel. Brake light will turn on
while rear brake is in use.
SHIFT PEDAL
This motorcycle is equipped with six-speed
constant mesh gearbox.
Caution:
When the transmission is on neutral position, the indicator lamp would turn
on. Slowly release the clutch lever to make sure the transmission is on the
neutral position.
Generally speaking, when the spring preload is increased, the rebound damping should also be increased
accordingly. If you are not sure how to adjust the rear suspension correctly, please refer to the authorized dealers for
technical advice.

Benelli TRK 502X Specifications

General

Displacement	500 cc
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Max Power	47.6 HP (35 kW) @ 8500 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Steel Trellis
Ground Clearance	220 mm
Fuel Tank Capacity	20 liters
Weight (Dry)	213 kg
Engine Type	Liquid cooled, 4-stroke, 2-cylinder
Max Torque	46 Nm @ 6000 rpm
Fuel System	Electronic fuel injection
Front Suspension	50 mm upside-down fork, adjustable
Rear Suspension	Single shock, adjustable
Front Brake	320 mm double disc, ABS
Rear Brake	260 mm single disc, ABS
Front Tire	110/80 R19
Rear Tire	150/70 R17
Seat Height	840 mm
