Benelli TRK 502X User Manual

TRK 502/ 502X
51
Ination pressure and tire tread should be regularly checked. In order to ensure maximum safety and longer
service life, ination pressure requires more frequent routine check.
Tire Pressure
Insucient tire pressure will not only accelerate wearing, but also have bad impact on driving stability such as
making turning dicult. However, too high pressure will reduce the contact area between tire and ground, thus
causing slipping or even getting out of control. Tire pressure should be kept in the standard range. Adjust the tire
pressure under a "cold" condition.
INSPECTION& MAINTENANCE
Notice:
Adjustment of valve clearance will have direct inuence on the performance of engine, thus requiring
strict accordance with the time interval required in "Maintenance Schedule". Adjustment should be done
with professional technicians corresponding tools. In order to keep the valve clearance in good condition,
we strongly recommend you to leave it up to consult to authorized dealers about this maintenance.
220kpa
Front Wheel
250kpa
Rear Wheel
TIRE

Benelli TRK 502X Specifications

General

Displacement	500 cc
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Max Power	47.6 HP (35 kW) @ 8500 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Steel Trellis
Ground Clearance	220 mm
Fuel Tank Capacity	20 liters
Weight (Dry)	213 kg
Engine Type	Liquid cooled, 4-stroke, 2-cylinder
Max Torque	46 Nm @ 6000 rpm
Fuel System	Electronic fuel injection
Front Suspension	50 mm upside-down fork, adjustable
Rear Suspension	Single shock, adjustable
Front Brake	320 mm double disc, ABS
Rear Brake	260 mm single disc, ABS
Front Tire	110/80 R19
Rear Tire	150/70 R17
Seat Height	840 mm
