Benelli TRK 502X User Manual

TRK 502/ 502X
47
Check the braking system everyday as follows:
1. Whether leak on the front and rear wheel braking system;
2. Whether leak, crack on the brake uid tubes;
3. Check the feedback feeling on brake lever
4. Check abrasion condition of the front and rear wheel brake pads
Rear Brake
To adjust the stroke of rear brake pedal, screw or turn the adjusting bolt of rear brake, the free play be
adjusted to 5~20mm.
INSPECTION& MAINTENANCE
Warning：
Maintenance of braking system or brake pads should be taken by the authorized dealer which is
equipped with necessary tools and can assure the quality of the service.
Caution:
The disk braking system has high pressure in the pipe require periodical maintenance in the manual.

Benelli TRK 502X Specifications

General

Displacement	500 cc
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Max Power	47.6 HP (35 kW) @ 8500 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Steel Trellis
Ground Clearance	220 mm
Fuel Tank Capacity	20 liters
Weight (Dry)	213 kg
Engine Type	Liquid cooled, 4-stroke, 2-cylinder
Max Torque	46 Nm @ 6000 rpm
Fuel System	Electronic fuel injection
Front Suspension	50 mm upside-down fork, adjustable
Rear Suspension	Single shock, adjustable
Front Brake	320 mm double disc, ABS
Rear Brake	260 mm single disc, ABS
Front Tire	110/80 R19
Rear Tire	150/70 R17
Seat Height	840 mm
