Benelli TRK 702 User Manual

3 - 15
Instrument and control functions
EN
3
NOTICE
Be careful not to damage the wheel
sensor or wheel sensor rotor; otherwi-
se, improper performance of the ABS
will result.
1
2
1. Front wheel speed sensor
2. Front sensor rotor
1
2
1. Rear wheel speed sensor
2. Rear sensor rotor
Fuel tank cap
To open the fuel tank cap
Lift the fuel tank cap lock cover, insert the
key into the lock, and then turn it 1/4 turn
clockwise. The lock opens and it is possi-
ble to raise the fuel cap.
To close the fuel tank cap
Close the fuel tank cap and turn the key
back to its original position by turning it
anticlockwise and then remove it.

Benelli TRK 702 Specifications

General

Displacement	698 cc
Bore x Stroke	83 mm x 64.5 mm
Compression Ratio	11.6:1
Fuel System	Electronic fuel injection
Transmission	6-speed
Final Drive	Chain
Seat Height	825 mm
Fuel Tank Capacity	20 liters
Engine Type	Liquid-cooled, 4-stroke, 2-cylinder
Maximum Torque	68.2 Nm @ 6, 250 rpm
Front Suspension	Upside-down telescopic fork
Rear Suspension	Monoshock, adjustable
Front Brake	Dual discs
Rear Brake	Single disc
Front Tire	110/80 R19
Rear Tire	150/70 R17
Weight	220 kg
