Benelli TRK 702 User Manual

9 - 2
Consumer information
EN
9
Model label
The label of the model is applied to the
left side of the steering head.
Record the information on this label in the
space provided. This information will be
needed when ordering spare parts from a
Benelli dealer.
WARNING
Any changes to the ID number stamped
on the frame or engine will automati-
cally render the warranty null and void.
Diagnostic connector
The diagnostic connector is located as
shown.
B-Box connector
The B-Box device, where it is available, can
be connected via the connector in the
gure, collects and sends data relating
to GPS tracking , as route traveled, speed,
distance, travel time, etc. visible through
the “MyBenelli” app.

Benelli TRK 702 Specifications

General

Displacement	698 cc
Bore x Stroke	83 mm x 64.5 mm
Compression Ratio	11.6:1
Fuel System	Electronic fuel injection
Transmission	6-speed
Final Drive	Chain
Seat Height	825 mm
Fuel Tank Capacity	20 liters
Engine Type	Liquid-cooled, 4-stroke, 2-cylinder
Maximum Torque	68.2 Nm @ 6, 250 rpm
Front Suspension	Upside-down telescopic fork
Rear Suspension	Monoshock, adjustable
Front Brake	Dual discs
Rear Brake	Single disc
Front Tire	110/80 R19
Rear Tire	150/70 R17
Weight	220 kg
