3 - 20
Instrument and control functions
EN
3
TRK702 Shock absorber setting
Comfort
Sport
Comfort
Sport
-13 clicks from fully closed
-11 clicks from fully closed
Ring nut 37 mm from end of stroke
Ring nut 39 mm from end of stroke
SHOCK ABSORBER ADJUSTMENT
TRK 702
REBOUND DAMPING
SPRING PRELOAD
2
1
1. Spring preload
2. Rebound damping
TRK702 front fork setting
NOTICE
There’s no adjustment on the standard
fork.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Benelli TRK 702 and is the answer not in the manual?

Benelli TRK 702 Specifications

General IconGeneral
Displacement698 cc
Bore x Stroke83 mm x 64.5 mm
Compression Ratio11.6:1
Fuel SystemElectronic fuel injection
Transmission6-speed
Final DriveChain
Seat Height825 mm
Fuel Tank Capacity20 liters
Engine TypeLiquid-cooled, 4-stroke, 2-cylinder
Maximum Torque68.2 Nm @ 6, 250 rpm
Front SuspensionUpside-down telescopic fork
Rear SuspensionMonoshock, adjustable
Front BrakeDual discs
Rear BrakeSingle disc
Front Tire110/80 R19
Rear Tire150/70 R17
Weight220 kg
