Benelli TRK 702 User Manual

6 - 32
Periodic maintenance and adjustment
EN
6
Troubleshooting charts
Starting problems or poor engine performance
Check the fuel level in
the fuel tank.
1. Fuel
There is enough fuel.
There is no fuel.
Check the battery.
Supply fuel.
The engine does not start.
Check the battery.
Remove the spark plugs
and check the electrodes.
3. Ignition
Wipe o with a dry cloth and correct the
spark plug gaps, or replace the spark plugs.
Have a Benelli dealer check the vehicle.
Operate the electric starter.
4. Compression
There is compression.
There is no compression.
The engine does not start.
Have a Benelli dealer check the vehicle.
Have a Benelli dealer check the vehicle.
The engine does not start.
Check the compression.
Operate the electric starter.
2. Battery
The engine turns over
quickly.
The engine turns over
slowly.
The engine does not start.
Check the ignition.
The battery is good.
Check the battery lead connections,
and have a Benelli dealer charge
the battery if necessary.
Dry
Wet
Operate the electric starter.

Benelli TRK 702 Specifications

General

Displacement	698 cc
Bore x Stroke	83 mm x 64.5 mm
Compression Ratio	11.6:1
Fuel System	Electronic fuel injection
Transmission	6-speed
Final Drive	Chain
Seat Height	825 mm
Fuel Tank Capacity	20 liters
Engine Type	Liquid-cooled, 4-stroke, 2-cylinder
Maximum Torque	68.2 Nm @ 6, 250 rpm
Front Suspension	Upside-down telescopic fork
Rear Suspension	Monoshock, adjustable
Front Brake	Dual discs
Rear Brake	Single disc
Front Tire	110/80 R19
Rear Tire	150/70 R17
Weight	220 kg
