Benelli TRK 702 User Manual

6 - 33
Periodic maintenance and adjustment
EN
6
Engine overheating
WARNING
• Do not remove the radiator cap when the engine and radiator are hot. Scalding hot uid and steam may be blown out under
pressure, which could cause serious injury. Be sure to wait until the engine has cooled.
• Place a thick rag, like a towel, over the radiator cap, and then slowly rotate the cap counterclockwise to the detent to allow
any residual pressure to escape.
• When the hissing sound has stopped, press down on the cap while turning it counterclockwise, and then remove the cap.
TIP
If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as
possible.
Wait until the
engine has cooled.
Check the coolant level in the
reservoir and radiator.
The coolant level
is OK.
The coolant level is low.
Check the cooling system
for leakage.
Have a Benelli dealer check
and repair the cooling system.
Add coolant. (See TIP.)
Start the engine. If the engine overheats again, have a
Benelli dealer check and repair the cooling system.
There is
leakage.
There is
no leakage.

Benelli TRK 702 Specifications

General

Displacement	698 cc
Bore x Stroke	83 mm x 64.5 mm
Compression Ratio	11.6:1
Fuel System	Electronic fuel injection
Transmission	6-speed
Final Drive	Chain
Seat Height	825 mm
Fuel Tank Capacity	20 liters
Engine Type	Liquid-cooled, 4-stroke, 2-cylinder
Maximum Torque	68.2 Nm @ 6, 250 rpm
Front Suspension	Upside-down telescopic fork
Rear Suspension	Monoshock, adjustable
Front Brake	Dual discs
Rear Brake	Single disc
Front Tire	110/80 R19
Rear Tire	150/70 R17
Weight	220 kg
