2 INTERFACE
2.1 Description About Wiring Sequence
TF02-Pro has an 80cm long connecting wire with a 1.25-4P connector, which shown in
Figure 2-1.
Figure 2-1TF02-Pro external wiring connector and wiring sequence
The wiring sequence is shown in Table 2-1.
Table 2-1 The Function Description of Each Wire
2.2 Electrical Characteristics
TF02-Pro has no overvoltage nor polarity protection, so please make sure that
connection and power supply is normal.
Table 2-2 Main Electrical Parameters of TF02-Pro
