Benford 5000 - Lubrication Points and Lubricants 2, 3, 4, 5 and 6 Tonne Swing

June 2004 - 9507EL/5
3-10
2 to 9 Tonne Dumper Instruction Manual
Lubrication Points and Lubricants 2, 3, 4, 5 and 6 Tonne Swing
Lubrication
Gearbox 2 & 3 Tonne
Gearbox 4 to 6Tonne
Gearbox ITL
1
Clutch Withdrawal
Shaft 2 & 3 Tonne
Only (Check Free Play)
2 2
1
Drive Shaft
Couplings
1
Steer
Ram
Pivots
1
Skip Ram
Pivots
1
Skip Pivots
1
Drive Shaft Couplings
2
2
Transfer Box
1
Handbrake Cable
1
Brake, Clutch and
Accelerator Linkage
5
Brake Reservoir
3
3
Front Axle
4
4
Engine
Sump
3
3
Rear Axle
6
Fuel Tank
5
5
1
Slew Ram
Pivots
7
Centre Pivot
5
Slew Ring
1 ......... Multi-Purpose Grease 5 ......... HDZ46 Daily
2 ......... SAE 85W/90 6 ......... Diesel Weekly
3 ......... Mobilfluid 422 or Texaco AS Trans. 7 ......... Texaco Multifac EP2 Grease Monthly
4 ......... SAE 10W/30 - 2 & 3 Tonne 8 ......... Texomatic C3 Six Monthly
........... SAE 15W/40 - 4, 5, 6000 & 2/3000 Deutz 9 ......... Texamatic 9330
Radiator Coolant Level
(4 to 6 tonne ONLY)
Hydraulic Tank
8 8
9 9
