Parts of the display and their functions16
PC-AUDIO
Connects with the VGA video source (via a 3.5mm cable) to
receive audio from the device.
AUDIO-OUT Connects to external speakers or earphones.
RS232
Connects with the serial I/O connector of a device to transfer
data.
LAN2
• Connects with a local network using a standard Ethernet cable.
• Supports 10/100 Mbps transmission speed.
LAN1
• Connects with a local network using a standard Ethernet cable.
• Supports 10/100 Mbps transmission speed.
OPS Slot
Supports installation of an OPS (Open Pluggable Specification)
device.
No. Name Description
• USB2.0= 5V 500mA / USB3.0= 5V 1.0A
• OPS= 18V 5A
• : Direct Current / DC
• : Alternating Current /AC
• The maximum length for the cables to be used with the USB slots are 5m (USB 2.0) and 3m
(USB 3.0).
• The product is designed for IT power distribution system with phase-to-phase voltage 230V.
