BenQ LU9750 - Page 24

English
24
Lens
Short Throw
(LS1ST3A)
Semi Throw
(LS2ST4)
Throw ratio 0.77~1.1 1.25~1.60
Diagonal Image Width Image Height
Offset (A) O Distance Distance
Wide/Tele Wide/Tele Wide Tele Wide Tele
(Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m)
50 1.27 42 1.08 26 0.67 1.3 0.034 14.6 0.370 33 0.83 47 1.18 53 1.35 68 1.72
60 1.52 51 1.29 32 0.81 1.6 0.040 17.5 0.444 39 1.00 56 1.42 64 1.62 81 2.07
80 2.03 68 1.72 42 1.08 2.1 0.054 23.3 0.592 52 1.33 75 1.90 85 2.15 109 2.76
100 2.54 85 2.15 53 1.35 2.6 0.067 29.1 0.740 65 1.66 93 2.37 106 2.69 136 3.45
120 3.05 102 2.58 64 1.62 3.2 0.081 35.0 0.888 78 1.99 112 2.84 127 3.23 163 4.14
150 3.81 127 3.23 79 2.02 4.0 0.101 43.7 1.111 98 2.49 140 3.55 159 4.04 204 5.17
180 4.57 153 3.88 95 2.42 4.8 0.121 52.5 1.333 118 2.99 168 4.26 191 4.85 244 6.20
200 5.08 170 4.31 106 2.69 5.3 0.135 58.3 1.481 131 3.32 187 4.74 212 5.38 271 6.89
250 6.35 212 5.38 132 3.37 6.6 0.168 72.9 1.851 163 4.15 233 5.92 265 6.73 339 8.62
300 7.62 254 6.46 159 4.04 7.9 0.202 87.4 2.221 196 4.98 280 7.11 318 8.08 407 10.34
350 8.89 297 7.54 185 4.71 9.3 0.236 102.0 2.591 229 5.80 326 8.29 371 9.42 475 12.06
400 10.16 339 8.62 212 5.38 10.6 0.269 116.6 2.962 261 6.63 373 9.48 424 10.77 543 13.79
500 12.70 424 10.77 265 6.73 13.2 0.337 145.7 3.702 326 8.29 466 11.85 530 13.46 678 17.23
Lens
Semi Long
(LS1LT0)
Throw ratio 1.93~2.9
Diagonal Image Width Image Height
Offset (A) O Distance
Wide/Tele Wide/Tele Wide Tele
(Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m)
50 1.27 42 1.08 26 0.67 1.3 0.034 14.6 0.370 82 2.08 123 3.12
60 1.52 51 1.29 32 0.81 1.6 0.040 17.5 0.444 98 2.49 148 3.75
80 2.03 68 1.72 42 1.08 2.1 0.054 23.3 0.592 131 3.33 197 5.00
100 2.54 85 2.15 53 1.35 2.6 0.067 29.1 0.740 164 4.16 246 6.25
120 3.05 102 2.58 64 1.62 3.2 0.081 35.0 0.888 196 4.99 295 7.50
150 3.81 127 3.23 79 2.02 4.0 0.101 43.7 1.111 245 6.24 369 9.37
180 4.57 153 3.88 95 2.42 4.8 0.121 52.5 1.333 295 7.48 443 11. 24
200 5.08 170 4.31 106 2.69 5.3 0.135 58.3 1.481 327 8.31 492 12.49
250 6.35 212 5.38 132 3.37 6.6 0.168 72.9 1.851 409 10.39 615 15.62
300 7.62 254 6.46 159 4.04 7.9 0.202 87.4 2.221 491 12.47 738 18.74
350 8.89 297 7.54 185 4.71 9.3 0.236 102.0 2.591 573 14.55 861 21.86
400 10.16 339 8.62 212 5.38 10.6 0.269 116.6 2.962 655 16.63 984 24.99
500 12.70 424 10.77 265 6.73 13.2 0.337 145.7 3.702 818 20.79 1230 31.23
Lens
Semi Long 2
(L S1LT1)
Long Zoom 1
(L S1LT2)
Throw ratio 2.22~3.67 3.58-5.38
Diagonal Image Width Image Height
Offset (A)
O Distance Distance
Wide/Tele Wide/Tele Wide Tele Wide Tele
(Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m) (Inch) (m)
50 1.27 42 1.08 26 0.67 0.0 0.000 13.2 0.337 94 2.39 156 3.95 152 3.86 228 5.79
60 1.52 51 1.29 32 0.81 0.0 0.000 15.9 0.404 113 2.87 187 4.74 182 4.63 274 6.95
80 2.03 68 1.72 42 1.08 0.0 0.000 21.2 0.538 151 3.83 249 6.32 243 6.17 365 9.27
100 2.54 85 2.15 53 1.35 0.0 0.000 26.5 0.673 188 4.78 311 7.90 304 7.71 456 11. 59
120 3.05 102 2.58 64 1.62 0.0 0.000 31.8 0.808 226 5.74 373 9.49 364 9.25 547 13.91
150 3.81 127 3.23 79 2.02 0.0 0.000 39.7 1.010 282 7.17 467 11. 8 6 455 11. 57 684 17. 38
180 4.57 153 3.88 95 2.42 0.0 0.000 47.7 1.212 339 8.61 560 14.23 546 13.88 821 20.86
200 5.08 170 4.31 106 2.69 0.0 0.000 53.0 1.346 377 9.56 622 15.81 607 15.42 912 23.18
250 6.35 212 5.38 132 3.37 0.0 0.000 66.2 1.683 471 11.95 778 19.76 759 19.28 1141 28.97
300 7.62 254 6.46 159 4.04 0.0 0.000 79.5 2.019 565 14.35 934 23.71 911 23.13 1369 34.76
350 8.89 297 7.54 185 4.71 0.0 0.000 92.7 2.356 659 16.74 1089 27.67 1063 26.99 1597 40.56
400 10.16 339 8.62 212 5.38 0.0 0.000 106.0 2.692 753 19.13 1245 31.62 1214 30.84 1825 46.35
500 12.70 424 10.77 265 6.73 0.0 0.000 132.5 3.365 941 23.91 1556 39.52 1518 38.56 2281 57.94
