Appendix
Timing table
HDMI Input (Support Video Timings)
Timing Resolution
Horizontal
frequency
(KHz)
Vertical
frequency
(Hz)
Dot Clock
Frequency
(MHz)
User
Manual
Supported
3D
Field
3D
frame
packing
3D
over-
under
3D
side-by-
side
480i
720(1440) x
480
15.73 59.94 27 Yes
◎
480p 720 x 480 31.47 59.94 27 Yes
◎
576i
720(1440) x
576
15.63 50 27 Yes
576p 720 x 576 31.25 50 27 Yes
720/50p 1280 x 720 37.5 50 74.25 Yes
◎ ◎ ◎
720/60p 1280 x 720 45 60 74.25 Yes
◎ ◎ ◎ ◎
1080/24P 1920 x 1080 27 24 74.25 Yes
◎ ◎ ◎
1080/25P 1920 x 1080 28.13 25 74.25 Yes
1080/30P 1920 x 1080 33.75 30 74.25 Yes
1080/50i 1920 x 1080 28.13 50 74.25 Yes
◎
1080/60i 1920 x 1080 33.75 60 74.25 Yes
◎
1080/50P 1920 x 1080 56.25 50 148.5 Yes
◎ ◎
1080/60P 1920 x 1080 67.5 60 148.5 Yes
◎ ◎
2160/24P 3840 x 2160 54 24 297 Yes
2160/25P 3840 x 2160 56.25 25 297 Yes
2160/30P 3840 x 2160 67.5 30 297 Yes
2160/50P 3840 x 2160 112 . 5 50 594 Yes
2160/60P 3840 x 2160 135 60 594 Yes
HDMI Input (Support PC Timings)
Resolution Mode
Refresh rate
(Hz)
Horizontal
frequency
(KHz)
Clock (MHz)
User Manual
Supported
3D Field
Sequential
3D over-
under
3D side-
by-side
640 x 480
VGA_60 59.94 31.469 25.175 Yes
◎ ◎ ◎
VGA_72 72.809 37.861 31.5 Yes
VGA_75 75 37.5 31.5 Yes
VGA_85 85.008 43.269 36 Yes
VGA _120** 119. 518 61.91 52.5 Yes
720 x 400 720x400_70 70.087 31.469 28.3221 Yes
800 x 600
SVGA_60 60.317 37.879 40 Yes
◎ ◎ ◎
SVGA_72 72.188 48.077 50 Yes
SVGA_75 75 46.875 49.5 Yes
SVGA_85 85.061 53.674 56.25 Yes
SVGA_120
(Reduce Blanking)
119.8 5 4 77.425 83 Yes
◎
1024 x 768
XGA_60 60.004 48.363 65 Yes
◎ ◎ ◎
XGA_70 70.069 56.476 75 Yes
XGA_75 75.029 60.023 78.75 Yes
XGA_85 84.997 68.667 94.5 Yes
XGA_120 (Reduce
Blanking)
119.9 8 9 97. 551 115 . 5 Yes
◎
1152 x 864 1152 x 864_75 75 67. 5 108 Yes
1024x576
BenQ Notebook
Timing
60 35.82 46.996 Yes
