BenQ MS527E - Page 72

Specifications
72
• The timings showing above may not be supported due to EDID file and
VGA graphic card limitations. It is possible that some timings cannot be
chosen.
Supported timing for Component-YPbPr input
2. HDMI Digital
Supported timing for PC input
1400 x 1050 SXGA+_60 59.978 65.317 121.750
◎◎
1600 x 1200 UXGA 60 75 162.000
◎◎
1680 x 1050
1680 x
1050_60
59.954 65.29 146.25
◎◎
1920 x 1080
1920 x
1080_60
(Reduce
Blanking)
67.5 60 148.5
1920 x 1200
1920 x
1200_60
(Reduce
Blanking)
59.95 74.038 154.000
640 x 480
@67Hz
MAC13 66.667 35 30.240
832 x 624
@75Hz
MAC16 74.546 49.722 57.280
1024 x 768
@75Hz
MAC19 75.02 60.241 80.000
1152 x 870
@75Hz
MAC21 75.06 68.68 100.000
Timing Resolution
Horizontal
Frequency
(KHz)
Ver tical
Frequency
(Hz)
Pixel
Frequency
(MHz)
3D Field
Sequential
480i 720 x 480 15.73 59.94 13.5
◎
480p 720 x 480 31.47 59.94 27
◎
576i 720 x 576 15.63 50 13.5
576p 720 x 576 31.25 50 27
720/50p 1280 x 720 37.5 50 74.25
720/60p 1280 x 720 45.00 60 74.25
◎
1080/50i 1920 x 1080 28.13 50 74.25
1080/60i 1920 x 1080 33.75 60 74.25
1080/24P 1920 x 1080 27 24 74.25
1080/25P 1920 x 1080 28.13 25 74.25
1080/30P 1920 x 1080 33.75 30 74.25
1080/50P 1920 x 1080 56.25 50 148.5
1080/60P 1920 x 1080 67.5 60 148.5
Resolution Timing
Horizontal
Frequency
(KHz)
Ver tical
Frequenc
y (Hz)
Pixel
Frequency
(MHz)
3D Field
Sequent
ial
3D
top
bott
om
3D
side
by
side
640 x 480
VGA_60 59.94 31.469 25.175
◎◎◎
VGA_72 72.809 37.861 31.500
VGA_75 75 37.5 31.500
VGA_85 85.008 43.269 36.000
720 x 400
720 x
400_70
70.087 31.469 28.3221
