9
No. Name Description
1
EARPHONE
Connects to external speakers or earphones.
This port does not support microphone function.
2
MIC-IN
Connects a microphone to send out amplified audio from the
display speaker.
This port only supports 3.5 mm TRS connector (2 rings).
3
TOUCH-USB Supports touch signal input from an external computer.
4
HDMI Connects to video sources that support the HDMI interface.
5
PUBLIC 3.0*
Connects USB-A devices such as keyboards, mouse, and USB
flash drives.
6
TYPE-C*
Connects to USB-C devices for power delivery and data transfer.
Supports the transmission of video, audio, and touch function.
7
Speakers Allows you to play audio directly form the display.
8
Ambient light sensor Detects the ambient light around the display.
9
IR signal receiver Receives infrared signals from remote control.
10
Power
• Tap to enter energy saving mode.
• Press and hold for 4 seconds or more to power off.
11
Home Returns to the main screen.
12
Return Returns to the previous menu.
13
Menu Enters the function menu.
14
Volume down Decreases the volume.
15
Volume up Increases the volume.
16
NFC sensor Tap NFC card for AMS login.
17
Array microphones Receives and transmits sound from near the display.
18
Camera Built-in camera for video conferences.
* With these smart ports, a laptop (connected to BenQ Board via USB Type-C or HDMI + Touch USB) can use
the USB devices, speakers, and external cameras from BenQ Board to enhance the conference experience.
Please note that the built-in array microphone can only be accessed by an OPS source.
