Connection18
Connecting the AV and S-Video inputs
1. Connect the AV IN(L/R) jack on the display to the output jack on an A/V device
(such as a VCR) using an appropriate video cable.
2. Connect the VCR’s audio output jacks to the AV OUT(L/R) jacks on the display
using a suitable audio cable.
3. To view video image from this input, press the INPUT button on the remote
control and select AV.
The cables are not supplied and should be purchased separately.
