3500 Galvanic Isolator Interface Manual
16
4. Wiring the Hardware
The 3500 Field Wiring Package (130432-01) shows how to connect transducers, power
supplies, and monitors to the interface modules. This section shows the location of the
connecting terminals and contains important precautions about safe and hazardous
area connections that you must consider before you use the drawings to connect
components.
WARNING
NON-Intrinsically Safe and Intrinsically Safe wiring MUST be separated by
50 mm minimum. Reference local wiring codes before wiring the
installation.
