3500 Galvanic Isolator Interface Manual
24
1
3
2
6
5
4
1
2
3
1) Vibration and Aeroderivative Cable Assembly
2) Keyphasor Cable Assembly
3) 25-way Male Connector with Straight Cable Entry (3500 Monitor)
4) 25-way Male Connector with 45
o
Cable Entry (Backplane)
5) 9-way Male Connector with Straight Cable Entry (3500 Monitor)
6) 9-way Male Connector with 45
o
Cable Entry (Backplane)
1) Cable
2) 45
o
Connector
3) Backplane
