Bentone B 30A - Technical data; Dimensions B 30; Dimensions flange

7 Bentone
165 105 22
2. Technical data
The burner is intended for:
• Light oil, B10 heating oil/biofuel blend (as defined in DIN V51603-6)
and is used for:
• Water heating generators
• Hot air generators (these require LMO 24 255 C2E)
2.1 Dimensions B 30
* Min. recommended distance to floor.
A Ø B Ø C D E F G H I * J
B 30
187/315 108 108 372 220 281 303 188 415 200
2.2 Dimensions flange
ø108
160-190
35
14
J
H
I
øB
øC
E
G
F
A
D
