ATIS TOP - Fancier
SUB-MENU CHECK
68
HB_TOP_ZUECHTER-E_22.doc
Gantner Pigeon Systems GmbH
Using the function key
quit
you get back to the previous display.
If a chip-code-ring is now held vertically over the antenna field of a loft antenna it will be
read and its contents will be displayed:
On the display you find: ring type (not only ATIS rings, number of the loft antenna over
which the chip-code-ring is being held and the storage contents.
Mind:
Approx. every second the antenna is newly read out and the result is newly
displayed. For control reasons a beep accompanies each reading process. In the case of
several connected antennae one after the other is called. If there are several chip code
rings on an antenna, one ring after the after will be displayed. Only one chip-code-ring per
reading field is permitted. To remember: The ATIS loft antennae are always equipped with
several antenna fields e.g. 8 per loft antenna. If there are two or more chip-code-rings on
one reading field none of these rings will be read out!
Using the function key
quit
you get back to the previous display.
** ringtest **
ringtype:ATIS ant:1
CB 33334
quit
Memory contents of ring
Ring type
Number of antenna on which ring is read
Headline
