BENZING ATIS TOP - ATIS Chip-Code Ring; Transformer; T-Adaptor

ATIS TOP - Fancier
TECHNICAL DATA
HB_TOP_ZUECHTER-E_22.doc 95
Gantner Pigeon Systems GmbH
Cable length: distance between tranformer and antenna: 500 m
(with each further antenna the max. cable length
is halved)
Housing: plastic
Operating temperature: 0° to +70°C
Storage temperature : -20° to +70°C
Protection: IP 52
17.3 ATIS-Chip-Code-Ring
Memory capacity: 128 Bit/64 Bit
Functions: read and write
Pincode: 4-digit
Data contents: identification number, pincode, pigeon number,
sex, year of birth/pigeon, club number, fancier`s
number, check sum
Housing: plastic
17.4 Transformer
Mains voltage: 230 V +
10 % 50/60 Hz/120 V
Output voltage: 13 V DC
Power consumption: 11 W
17.5 T-Adaptor
Operating voltage: 8 to 20 V DC, typical 12 V DC
Current: approx. 20 mA
Interface: RS-485
Indicating instrument: 2 LEDs (small signal lamps)
Housing: plastic
