ATIS TOP - Fancier
SUB-MENU CHECK
HB_TOP_ZUECHTER-E_22.doc
71
Gantner Pigeon Systems GmbH
13.3 Check: System
Attention: As long as the function check system is active, no pigeons can be registrated!
Therefore be cautious to apply this function during a race!
The increasing row of points in the bottom line of the display indicates that a test is going
on.
After the end of the system test the result will be displayed (now the pigeons are again
registered in the background):
The following data is displayed (in several lines):
Serial number: (SNr) The serial number internally stored in the ATIS-TOP is
displayed. It should correspond with the serial number of the
type label at the back of the device.
RAM-memory: (RAM) Is used for temporary storage of data, such as system data,
interim results, etc. These data are only saved as long as the
device is supplied with electricity. If the RAM-memory is all
right the display will show
“OK
“, if not it`ll show
„??“
.
FLASH-memory: (FLASH) Is used for longer storage of data such as lists of arrived ,
associated and registered pigeons, of races, of results, etc.
These data are saved for a period of up to 10 years even in
the case of a power failure. If the FLASH-memory is all right,
the display will show
„OK“,
if not it`ll show
„??“.
** systemtest **
testing
..................
** systemtest **
SNr: 123456
RAM: OK FLASH: OK
quit
Status of the RAM-memory test
Serial number of the device
Headline
Status of the FLASH memory test
