BENZING ATIS TOP User Manual

ATIS TOP - Fancier
SUB-MENU CONFIGURATION
86 HB_TOP_ZUECHTER-E_22.doc
Gantner Pigeon Systems GmbH
When calling the function Master / Slave in the sub-menu configuration you get the
following display:
With the 2 cursor keys you can select
MASTER or SLAVE .
Using the function key
choose the currently active configuration (Master or Slave) is
selected:
After a short beep the TOP restarts with the new selected configuration.
When you have selected the SLAVE configuration you will see this on the display.
Note : By setting the same pigeon for a race in both TOPs (Master and Slave) on same
time, the secret code will not be correct.
A slave can not be used without a Master, when you plug out the Master you have to
change the configuration of the Slave to a Master.
Master / Slave
MASTER
SLAVE
q
uit choose
GANTNER ELECTRONIC
NO RACE
01.04.20 15.11.36
SLAVE

BENZING ATIS TOP Specifications

General

Brand	BENZING
Model	ATIS TOP
Category	Clock
Language	English
