Berchtold CHROMOPHARE D 650plus - Technical Data and Specifications; 4.1 CHROMOPHARE D 650 plus Technical Data

22
CHROMOPHARE® D 650plus, D 530plus, D 500plus, D 650, D 530, D 500 Service Manual (E)
4.TECHNICAL DATA
4.1 CHROMOPHARE® D 650plus
Light technical dataD 650plus
Reflector systemPolygon reflector
Colour temperature4500 K3600 K
Intensity Ec at 1 m [klx]130150
Intensity control [klx]70 - 13070 - 150
Total radiant power at max intensity485 W/m
2
555 W/m
2
Total radiant power/intensity Ec [mW/m
2
lux]3,7
Colour rendering index R
a
94
Light field diameter15 – 28 cm15 – 28 cm
d
10
Light field dia. at 10% of max intensity15 cm15 cm
d
50
Light field dia. at 50% of max intensity8 cm8 cm
Remaining illuminance when beam is obstructed by
one mask47 %47 %
Remaining illuminance when beam is obstructed by
two mask45 %45 %
Remaining illuminance inside at the bottom of a
standardised tube.100 %100 %
Remaining illuminance inside at the bottom of a
standardised tube. Beam obstructed by one mask47 %47 %
Remaining illuminance inside at the bottom of a
standardised tube. Beam obstructed by two mask45 %45 %
Depth of illumination L1 + L2120 cm120 cm
Electrical data
Primary voltage of transformer100 / 120 / 127 V A.C.
220 / 230 / 240 V A.C.
Power consumption240 VA
or 170 AV at 24 V D.C.
Rated capacity of transformer / frequency240 VA / 50/60 Hz
Safety Category1
Protection provided by enclosureIP 53
General data
Halogen bulb
Order no.
22,8 V / 150 W
CZ 908-22
Life time of halogen bulb1000 h
Automatic switch over to reserve bulbyes
