CHROMOPHARE® D 650plus, D 530plus, D 500plus, D 650, D 530, D 500 Service Manual (E)
5.SERIAL NO. IDENTIFICATION
Type plate (A)
1Version number
2Variant
3Manufacturing year
4Serial number
6.SPARE PART LIST
6.1 CHROMOPHARE® D 650plus, D 650
DescriptionPart no.Picture on page
Filtering board6560640
Reverse polarity protection6560141
Light intensity power circuit board6560442
Hexagon socket countersunk head screw28443
Locking pin6417443
Sliding contact6418643
Brake screw3882143
Cross recessed oval-head screw27743
Distance sleeve6478343
Cover6417143
Contact block for sliding contacts3969343
Cross recessed oval-head screw23543
