CHROMOPHARE® D 650plus, D 530plus, D 500plus, D 650, D 530, D 500 Service Manual (E)
Ato EndoLite®, max. 11,0 V A.C. / D.C.
8.8 CHROMOPHARE® D 530plus, D 500plus, D 530, D 500
1Protection bush, part no. 20011
2Washer, part no. 24197
3Screw, part no. 11656
4Security lock – spring balanced arm, (not visible)
part no. 20010
Security lock – spring balanced arm, part no. 20010
