28
CHROMOPHARE® D 650plus, D 530plus, D 500plus, D 650, D 530, D 500 Service Manual (E)
4.4 CHROMOPHARE
®
D 530, D 500
Light technical dataD 530D 500
Reflector systemPolygon reflector
Colour temperature4500 K3600 K4500 K3600 K
Intensity Ec at 1 m [klx]11090
Intensity control [klx]55 - 110no
Total radiant power at max intensity410 W/m
2
336 W/m
2
Total radiant power/intensity Ec [mW/m
2
lux]3,7
Colour rendering index R
a
94
Light field diameter17 – 28 cm17 cm
d
10
Light field dia. at 10% of max intensity17 cm17 cm
d
50
Light field dia. at 50% of max intensity8,5 cm10 cm
Remaining illuminance when beam is obstructed by
one mask27 %31 %
Remaining illuminance when beam is obstructed by
two mask43 %42 %
Remaining illuminance inside at the bottom of a
standardised tube.100 %100 %
Remaining illuminance inside at the bottom of a
standardised tube. Beam obstructed by one mask27 %31 %
Remaining illuminance inside at the bottom of a
standardised tube. Beam obstructed by two mask43 %42 %
Depth of illumination L1 + L2130 cm130 cm
Electrical data
Primary voltage of transformer100 / 120 / 127 V A.C.
220 / 230 / 240 V A.C.
Power consumption240 VA
or 170 VA
at 24 V
D.C.
200 VA
or 140 VA
at 24 V
D.C.
240 VA
or 170 VA
at 24 V
D.C.
200 VA
or 140 VA
at 24 V
D.C.
Rated capacity of transformer / frequency240 VA / 50/60 Hz140 VA / 50/60 Hz
Safety Category1
Protection provided by enclosureIP 53
