CHROMOPHARE® D 650plus, D 530plus, D 500plus, D 650, D 530, D 500 Service Manual (E)
14.WIRING DIAGRAMS
14.1CHROMOPHARE® D 650plus, D 650
Transformer mounted on the ceiling tube
