Start-up
108 - 131
Operating manual, Dumper – 3012 PLUS
Status 28 April 2015
Bergmann Maschinenbau GmbH & Co. KG
10.6.3. Travel direction switch
To avoid jerky movements, actuate the travel direction switch only when travelling at low speed.
10.6.4. Brake pedal
When the brake pedal is pushed down, the brake cylinder is actuated, acting on a hydraulic brake valve.
The brake acts on both the front and rear axle (two-circuit brake system).
10.6.5. Parking brake
When the parking brake switch is actuated, the brake caliper in the gearbox is electrically applied. When
the brake circuit is depressurised, the brake is applied by spring force. This brake acts on the front axle
and is operated mechanically. The parking brake switch is located in the armrest of the joystick holder.
