Safety

20 - 131

Operating manual, Dumper – 3012 PLUS

Status 28 April 2015

Bergmann Maschinenbau GmbH & Co. KG

5.2. Emergency actions

 Cordon off site of accident

 Provide first aid

 Alert doctor, rescue services

 Look after casualties
