6.2. Axles
Front axle Rigid axle, self-aligning, flat-spring axle
Rear axle Rigid axle
Self-aligning angle ± 15° at centre piece
Drive type optional four-wheel drive
6.2.1. Tyres / tyre pressure
Diagonal tyres 20.5 R 25
Front tyre pressure 2.50 bar
Rear tyre pressure 4.75 bar
6.2.2. Brakes
Service brake: Encapsulated, long-life, maintenance-
free multi-disk brake with automatic
adjustment. Hydraulically operated
with brake pedal, acting on front and
rear wheels (two-circuit brake system).
Secondary and parking brake: Hydraulically operated spring-applied brake acting via the cardan shaft on
the front and rear axle.
