Operator stand / cab
Operating manual, Dumper – 3012 PLUS
81 - 131
28 April 2015
Bergmann Maschinenbau GmbH & Co. KG
Item 1
Handle
Item 2
Step
9. Operator stand / cab
9.1. Access to operator stand
The operator stand of the 3012 PLUS dumper is accessed from the left (front). To access the cab, always
use the handle (item 1) and the step in the bumper (item 2) (see fig. 9-3)!
Item 1
Fig. 9-1
Fig. 9-2
Item 2
Fig. 9-3
