Operator stand / cab
82 - 131
Operating manual, Dumper – 3012 PLUS
Status 28 April 2015
Bergmann Maschinenbau GmbH & Co. KG
Fig. 9-4
Item 1
Steering wheel with steering
knob
Item 2
Steering column switch
Item 3
Dashboard/display *
* definition
For flash codes of control
system,
see maintenance instructions
Fig. 12-8
9.2. Description of operator stand and cab
The operator stand (cab) is mounted on the front frame of the dumper. It is secured to the frame with
hydraulic bushings. The operator stand is designed as a separate unit. Its main components are shown
below.
Item 3
Item 2
Item 1
