bergmann 3012 PLUS - Dashboard

Operator stand / cab
Operating manual, Dumper – 3012 PLUS
91 - 131
28 April 2015
Bergmann Maschinenbau GmbH & Co. KG
Item 1
Left buttons
Item 2 Left dial indicator
Item 3 Right dial indicator
Item 4 Right buttons
Fig. 9-17
Item 5
Display (centre)
9.5. Dashboard
Fig. 9-27
Item 3
Item 2
Item 5
Item 4
Item 1
