Safety

62 - 131

Operating manual, Dumper – 3012 PLUS

Status 28 April 2015

Bergmann Maschinenbau GmbH & Co. KG

Fig. 5-36

Warning sign "Electrical hazard" / 1 label

Item no. 50-005-0005-900

Fig. 5-37

Warning sign "Caution" / 2 labels

Item no. 50-005-0014-90
