Operator stand / cab
88 - 131
Operating manual, Dumper – 3012 PLUS
Status 28 April 2015
Bergmann Maschinenbau GmbH & Co. KG
Joystick
- Switch 1 forward: Forward travel
- Switch 1 back: Reverse travel
- Press switch 2: Gear shift down
- Press switch 3: Gear shift up
- Joystick down: Lock
- Joystick up: Release
- Joystick forward: Lower trough
- Joystick back: Lift trough
- Joystick to right: Turn trough to the
right
- Joystick to left: Turn trough to the left
Fig. 9-21
1
2
3
