PREPARE TO MOUNT UNIT
Check to make sure truck batteries are still
disconnected. Carry unit into truck. It will
be mounted over the 4 ¾″ hole that was
drilled earlier. Make sure hoses and tubes
don’t get tangled or caught on anything.
Run Lines Through Cab Floor
Feed exhaust hose, intake hose, and fuel
line through the 4 ¾″ hole, making sure
they are not bent, crimped or rubbing on
the side of the hole.
Mount Heater Unit to Cab Floor
Make sure that the heater unit is set with
the fan (intake) end opposite the 2 ½″ hole
for the vent/louver drilled earlier. Set unit
flush to floor and attach with a self-
tapping screw at each corner of the
mounting plate.
