Electrical Installation
Install Separator Enclosure
Remove the enclosure cover, Place the
separator mounting bracket, centered on
the inside of the cover. Mark and drill 4
holes to secure the bracket to the cover.
Before installing the bracket, secure the
separator to the bracket with four
10 x 32 x ¾″ screws and lock washers
provided.
WIRING THE TERRA POWER SEPARATOR
Disregard the enclosure instructions if you mount
the separator inside the battery box.
