Bernard Controls AQ Switch Series User Manual

English
32
A – Power board
B – Positioner board
C – Switch board
D – Torque board (except on
AQ5/10/15)
H – Heater
RD – Fault relay
PT – Position transmitter
AI – Analog input setpoint
M3 – Motor
S1 – Counterclockwise direction
(normally for opening) – For
signalization
S2 – Clockwise direction (normally
for closing) – For signalization
S3 – Counterclockwise direction
(normally for opening) – For
detection
S4 – Clockwise direction (normally
for closing) – For detection
Power board - J2 terminal
Terminal
Comments
L1 to L3
Three phases supply
Positioner board - J6 terminal
Terminal
Comments
1 to 3
Travel limit switch – counterclockwise direction
4 to 6
Travel limit switch – clockwise direction
7 to 9
Fault relay (terminal 7-9 closed = actuator available)
10 and 11
Position transmitter (internally powered, 0/4-20 mA, 24 VDC)
12 and 13
Analog input setpoint
