Supertop
®
– Installation Instructions
Rev. G 0312 51599 pg. 2
Parts List and
Hardware Identifi cation
Top Fabric Qty - 1
Quarter Window, Right Qty - 1
Quarter Window, Left Qty - 1
Rear Window Qty - 1
#8 x 1/2" Pan Head Washer
Screw - Black, Qty - 13, Part
Number 200.48
5/16-18 x 1" Phillips Head Bolt,
Qty - 16, Part Number 236.20
5/16-18 Tapping Plate, Qty - 16,
Part Number 200.50
5/16" Black Washer,
Qty - 16, Part Num-
ber 233.04
Windshield Retainer - Right,
Qty - 1, Part Number 225.42
Windshield Retainer - Left,
Qty - 1, Part Number 225.43
#10 x 1/2" Pan Head Sheet
Metal Screw, Qty - 4, Part
Number 1.92
Corner Belt Rail, Right, Qty - 1,
Part Number 288.33
Corner Belt Rail, Left, Qty - 1,
Part Number 288.34
Bow Assembly - Right,
Qty - 1, Part Number
246.56
Bow Assembly - Left,
Qty - 1, Part Number
246.57
Vertical Retainer Mount, Left,
Qty - 1, Part Number 229.25
Vertical Retainer Mount, Right,
Qty - 1, Part Number 229.24
Windshield Bracket - Right,
Qty - 1, Part Number 137.96
Windshield Bracket - Left,
Qty - 1, Part Number 137.97
Tailgate Bar, Qty - 1,
Part Number 288.75
Side Belt Rail - Right, Qty - 1,
Part Number 225.04
Side Belt Rail - Left, Qty - 1,
Part Number 225.05
To Next Page
