Bestop Supertop - Install Top on Vehicle; Snap Top to Rear Bow

Supertop
®
– Installation Instructions
Rev. G 0312 51599 pg. 9
Install Top on Vehicle
Snap Top to Rear Bow
Secure Rear Corners
Locate the top and orient it on the vehicle. Drape
the top over the bows and insert the plastic strip
sewn along the front of the top into windshield
retainer attached on the front of the windshield
frame. Center the front of the deck on the vehicle
so that it is an equal distance from the top of the
windshield fl ange on both sides.
If the snaps don't appear to line up,
push the rear bow forward to relieve
the pressure on the bow. This will allow the snaps
to line up more easily.
Windshield
Driver's Side of Vehicle
Make sure space between top
fabric and windshield fl ange is
equal on both sides
For best possible installation, check to
make sure that the soft top is perfectly
centered on the vehicle.
View from inside top
Snap to bow
Bow
Snap the fl aps to the six studs on the rear bow.
Plastic Strip
Fabric
Windshield
Retainer
Make sure that
only Plastic Strip
is in retainer
Black Plastic
Strip
Rear Corner
Retainer
Fabric
Insert the black plastic strips at rear corners of top
into Corner Belt Rails. There is a plastic reinforce-
ment sewn into the corner of the top, in addition to
the plastic strip.
Make sure that the reinforcement is not caught
under the Corner Belt Rail.
Plastic
Reinforcement
