Beta LaserMike LASERSPEED 8000 User Manual

LaserSpeed 8000/9000 I/O Module Instruction Handbook
Setup
Part No. 93342 / Drawing No. 0921-01516 Page 47 of 84 Revision E (Dec 2013)
~I:DataFlag Parallel Port Data Output Polarity
~I:DataFlag<CR> Read Setting
Response Format:
ParallelPort DataFlag <N><CR>
~I:DataFlag=<N><CR> Set Value
Factory Default: 1 Minimum: 0 Maximum: 1
Where <N> indicates the polarity of the output Data. Data true high or Data true
low
Value
Logic ‘0’
Logic ‘1’
0
High Voltage
Low Voltage
1
Low Voltage
High Voltage
When operating the parallel output as an open collector output bus:
Value
Logic ‘0’
Logic ‘1’
0
Open
0V
1
0V
Open
Example: To set the Data Output Polarity to Active High, send the command
~I:DataFlag=1<CR>. To set the Data Output Polarity to Active Low, send
the command ~I:DataFlag=0<CR>.
