LaserSpeed 8000/9000 I/O Module Instruction Handbook
Setup
Part No. 93342 / Drawing No. 0921-01516 Page 48 of 84 Revision E (Dec 2013)
~I:AckMode Parallel Port Update Mode
~I:AckMode<CR> Read Setting
Response Format:
ParallelPort AckMode <N><CR>
~I:AckMode=<N><CR> Set Value
Factory Default: 0 Minimum: 0 Maximum: 1
Where <N> indicates the Parallel Port Update Mode.
When in Data Ready Mode, the I/O Module automatically updates the parallel
port when new data is received from the gauge. The update rate is determined
by the gauge’s update rate. When in Data Request Mode, the I/O Module
updates the parallel port when the Data Request Input is asserted. In this mode,
the update is rate is determined by the device controlling the Data Request
signal.
Example: To set the Parallel Port Update Mode to Data Ready Mode, send the
command ~I:AckMode=0<CR>. To set mode to Data Request Mode, send the
command ~I:AckMode=0<CR>.
