Extract the paper filter using pliers. Check
the condition of the O-ring too, and replace
it if necessary.
Change the filter and refit the cover, tighte-
ning the three M6x20 bolts to 10 Nm.
Refit the oil drainplug, tightening it to 20
Nm, and refill with 0.9 litres of engine oil
(BARDHAL XTC60 15W50). Finally, tighten
the oil filler plug (A) to 10 Nm.
BRAKE MASTER CYLINDER FLUID
Front brake
Use the sight-glass (A) to check the brake
fluid level. There must always be enough
brake fluid for the level to be visible in the
sight-glass. If there is not enough, the fluid
must be brought up to the correct level. To
do this, refill the reservoir by unscrewing
the two screws (B), removing the filler cap
(C) and topping up the fluid.
A
A
C
B
