oil level
130 mm
LEFT SHAFT
To replace the oil, proceed as follows:
Remove the front wheel.1.
Remove the front mudguard.2.
Loosen the shaft locking screws (A).3.
Unscrew the slider plug.4.
Remove the spacer and the spring, com-5.
press the fork to the end of the stroke,
then empty out all the oil.
Add oil (OJ01), up to the level shown in 6.
the figure.
Reinsert the spring and the spacer then 7.
replace cap.
Put the shaft back on the fork triple 8.
clamps, tightening the screws (A) to 0.85
kgm.
Note
Change the fluids in accordance with the inter-
vals in the table on page 71, using the lubricants
recommended on page 53.
Check periodically and, if necessary, remove
any residues of dirt that may remain between
the fork seal and the dust cover, by removing the
dust cover.
Note
Recommended tightening torque 7.8: 9.1 Nm.
SPARKPLUG
Keeping the sparkplug in good condition helps
to reduce fuel consumption and keep the en-
gine running optimally.
To check it, just pull off the plug cap and un-
screw the sparkplug.
Check the gap between the electrodes with a
feeler gauge: it should be 0.6-0.7 mm. If it is
not within this range, you can adjust it by ben-
ding the negative electrode. Take care not to
damage the central electrode.
Check also that there are no cracks in the in-
sulation or corroded electrodes. If you find
either of these faults, replace the sparkplug
immediately.
Check the sparkplug at the intervals given
in the table on page ......
The best way to fit the sparkplug is to screw
it in by hand until it will go no further, then
lock it with a spanner.
Note
We recommend that you always use NGK CR7EB
sparkplugs.
